REPEATER AND DUPLEX OPERATIONS
New2001
■ Duplex operation
Although [DIAL] and [ ](5) are used for description in this
section, [
](2)/[ ](8) and [ ](6) are available instead of
[DIAL] and [
](5).
D Setting offset frequency
q Enter “OFFSET FREQ” in DUP/TONE… set mode. (p. 110)
w Rotate [DIAL]
†
to set offset frequency.
• 1 MHz and 10 MHz tuning steps are available by pushing and
holding [MHz](VFO) for 1 sec.: push [MHz](VFO) to cancel it.
e Push [ ](5) (or [ ](4)) to return to DUP/TONE… set
mode, and push [MENU/
] to return to frequency indi-
cation.
D Setting duplex direction
➥ Push and hold [DUP](4) for 1 sec. to select “–DUP” (neg-
ative offset) or “+DUP” (positive offset).
• “–DUP” or “+DUP” indicates the transmit frequency for minus
shift or plus shift, respectively.
• When offset frequency is 0.6 MHz.
†
[DIAL] ↔ [ ](2)/[ ](8)
‡
[ ](5) ↔ [ ](6)
0.6 MHz offset
No offset frequency
0.600.00
0.600.00
OFFSET FREQ
OFFSET FREQ
0.000.00
0.000.00
OFFSET FREQ
OFFSET FREQ
4
DUP
–Duplex example +Duplex example
Receiving
Transmitting
A
A
TONE
TONE
FM
FM
145300
145300
PSKI
PSKIP
-DUP
-DUP
A
TONE
TONE
FM
FM
144700
144700
PSKI
PSKIP
-DUP
-DUP
Receiving
Transmitting
A
TONE
TONE
FM
FM
145300
145300
PSKI
PSKIP
+DUP
+DUP
A
TONE
TONE
FM
FM
145900
145900
PSKI
PSKIP
+DUP
+DUP
❮MENU screen❯ ➪ ❮DUP/TONE…❯ ➪ ❮OFFSET FREQ❯
(Push [MENU/ ]) (Rotate [DIAL]
†
, then push [ ](5)
‡
.)
