GPS/GPS-A OPERATION
New2001
D Displaying own/received position data with
compass
Displaying own direction, received station’s direction and set
position and direction in the GPS memory.
q Enter “COMPAS” in message/position set mode.
• COMPAS screen is displayed.
w Rotate [DIAL]
†
to select the received position data indica-
tion.
• MY, RX or SET is available.
[Indication items]
• MY : Displays own latitude, longitude, elevation, the time
and direction.
• RX : Displays other station latitude, longitude, distance
from own and direction.
• SET : Displays latitude, longitude, distance from own posi-
tion and direction of alarm setting for GPS memory.
e Push and hold [S.MR](MR) for 1 sec. to save the selected
position data to GPS memory (CH00).
• The M-CH number advances automatically in case the next
M-CH is already contains information.
• 100 GPS M-CH are available.
• Push [MR] to display stored position data.
r Push [ ](5) (or [ ](4)) to return to MESSAGE/POSITION
screen.
t Push [MENU/
] to return to frequency indication.
❮MENU screen❯ ➪ ❮MESSAGE/POSITION❯ ➪ ❮COMPAS❯
(Push [MENU/ ]) (Rotate [DIAL]
†
, then push [ ](5)
‡
.)
35
35°
45
45.00 N
NORTH
NORTH
UP
UP
ELEVAT
ELEVAT
EW
N
S
15m
15m
TIME
TIME
21:00
21:00
135
135°
36
36.00 E
MY
MY
