Icom IC-E92D Instruction Manual

134
D Receiver
• Receive system :
Except WFM Double-conversion superheterodyne
WFM Triple-conversion superheterodyne
• Intermediate frequencies :
1st A band 61.65 MHz/59.25 MHz
(WFM only)
B band 46.35 MHz
2nd 450 kHz/13.35 MHz (WFM only)
3rd 1.95 MHz (WFM only)
• Sensitivity (except spurious points):
AM (1 kHz/30% Mod.; 10 dB S/N)
0.495–4.995 MHz 1.3 µV typ.
5.000–29.995 MHz 0.56 µV typ.
118.000–137.000 MHz 0.5 µV typ.
222.000–246.995 MHz 0.79 µV typ.
247.000–329.995 MHz 1 µV typ.
FM
(1 kHz/3.5 kHz Dev.; 12 dB SINAD)
VHF (Amateur band only) 0.14 µV typ.
UHF (Amateur band only) 0.16 µV typ.
1.625–29.995 MHz 0.4 µV typ.
30.000–117.995 MHz 0.25 µV typ.
118.000–173.995 MHz 0.14 µV typ.
174.000–259.995 MHz 0.32 µV typ.
260.000–349.995 MHz 0.32 µV typ.
350.000–469.995 MHz 0.16 µV typ.
470.000–599.995 MHz 0.32 µV typ.
600.000–999.990 MHz 0.56 µV typ.
WFM
(1 kHz/52.5 kHz Dev.; 12 dB SINAD)
76.000–108.000 MHz 1 µV typ.
175.000–221.995 MHz 1.8 µV typ.
470.000–770.000 MHz 2.5 µV typ.
DV
(digital/PN9 4.8 kbps; BER 1%)
VHF (Amateur band only) 0.22 µV typ.
UHF
(Amateur band only) 0.22 µV typ.
• Audio output power : More than 200 mW at 10% distortion
(at 7.4 V DC) with an 8 Ω load
• Selectivity :
FM
(Wide), AM More than 50 dB
FM (Narrow), DV More than 45 dB
WFM More than 300 kHz/–3 dB
Less than 700 kHz/–20 dB
• Ext. speaker connector : 3-conductor 3.5(d) mm; (
1
⁄8˝)/8 Ω
• Spurious and image rejection ratio :
VHF More than 60 dB
UHF More than 50 dB
(Intermediate freq.; More than 60 dB)
• Squelch Sensitivity
(except spurious points):
AM (1 kHz/30% Mod.)
0.495–4.995 MHz 1.3 µV typ.
5.000–29.995 MHz 0.56 µV typ.
118.000–137.000 MHz 0.5 µV typ.
222.000–246.995 MHz 0.79 µV typ.
247.000–329.995 MHz 1 µV typ.
FM (1 kHz/3.5 kHz Dev.)
1.625–29.995 MHz 0.4 µV typ.
30.000–75.995 MHz 0.25 µV typ.
76.000–117.995 MHz 0.25 µV typ.
118.000–173.995 MHz 0.14 µV typ.
174.000–259.995 MHz 0.32 µV typ.
260.000–349.995 MHz 0.32 µV typ.
350.000–469.995 MHz 0.16 µV typ.
470.000–599.995 MHz 0.32 µV typ.
600.000–999.990 MHz 0.56 µV typ.
WFM
(1 kHz/52.5 kHz Dev.)
76.000–108.000 MHz 1 µV typ.
175.000–221.995 MHz 1.8 µV typ.
470.000–770.000 MHz 2.5 µV typ.
New
15
SPECIFICATIONS
New2001

Icom IC-E92D Specifications

General

Brand	Icom
Model	IC-E92D
Category	Transceiver
Language	English
