Base Unit Specications
ITEM DESCRIPTION SPECIFICATIONS
Power Vin +9 to +36 VDC
Radio
Frequency 2405–2480MHz @ 100mW
License None required
Modulation
Channel-Hopping Direct Sequence Spread Spectrum (CH
DSSS)
Antenna Internal
Environment
Operating Temp –20° C to 70° C (–4° F to 158° F)
Storage Temp –40° C to 85° C (–40° F to 185° F)
Humidity 0 to 100%
Vibration/Shock
IEC60068-2-6
10 Hz to 150 Hz @ 1.0 g peak acceleration
10.0 g peak shock acceleration
Indicators (5)
CAN 1 TX/RX TX=red, RX=green; Flashes upon event
CAN 2 TX/RX TX=red, RX=green; Flashes upon event
ERR/HLTH Error= red, Health=green; blinks 1x/sec
RF TX/RX TX=red, RX=green; Flashes upon event
POWER Amber; solid when normal; Flashes upon event
Enclosure
Dimensions 119 mm x 133 mm x 36 mm (5.24” x 4.69” x 1.42”)
Durability High Impact Polymer
Mounting Holes
7.4 mm (0.29”) dia. 102 mm center-to-center (4” center-to-
center)
Serial Parts
Two CAN
One RS-232
Base Unit LED Diagnostic Troubleshooting
INDICATION DIAGNOSIS / PRESCRIPTION
Power LED not active
Is +VDC input power present?
Check input power polarity.
CAN TX/RX 1/2 not active RF TX/RX LED not active
Check for obstructions preventing line-of-sight
transmission.
Check that the handheld remote is active.
Re-associate the handheld remote to the base unit.
Health LED ashing rapidly
Indicates an internal problem. Contact IMT Technical
Support.
ERR LED active
Check the outputs for loose wiring, etc.
Check to see if current output or voltage input is out of
bounds
Base Unit Details
FIELDS
DESCRIPTION NOTES
Control Power 9–36 VDC Using 12 VDC
Radio Frequency (RF) 2400 MHZ 2405–2480 MHz @ 100 mW
Antenna Option Internal
Can Conguration SAE J1939
Can 1 EPG Connection Includes internal termination (120 Ώ)
Can 2 Crane Connection Does not include termination
RS-232 Debug/Program Terminal
