GM/IH CV Chassis PTO Setup
GM / IH CV CHASSIS PTO SETUP
Upon arrival at the worksite and while the engine is running:
1. Engage the E-Brake.
2. Enable the cruise control from the steering wheel controls, then
disable the cruise control while observing the indicator light on the dash.
(Enable: light is on, Disable: light is off)
3. Engage the PTO by either using:
• In-dash switch inside the cab.
• CMD.CTRL™ body controls (Crane remote, or Auto PTO)
NOTE:
If the CMD.CTRL body controls were used for engine STOP, you must wait a minimum of
30 seconds before remote START can be activated. Attempting a remote START in less
than 30 seconds from remote engine STOP, can result in chassis, or PTO not respond-
ing. If the PTO has been disengaged, the GM and IH CV chassis requires a minimum 30
seconds to reconfigure before PTO engage can be activated by either using:
• In-dash switch inside the cab
• CMD.CTRL™ body controls (Crane remote, or Auto PTO)
NOTE:
The horn will honk three (3) times indicating when the PTO is starting. If after 15 seconds
the PTO has NOT started, repeat the PTO engage request. It is not uncommon for the
PTO engage to NOT respond after multiple attempts with a GM and IH CV chassis. If the
PTO will NOT engaged after multiple attempts, the chassis will need to be reset by:
• Turning engine off and removing the ignition key.
• Waiting until the chassis has completely powered down. (This can take up to
one minute)
This chart is to be used as a “quick reference” guide only.
It should not be substituted for a thorough review of the manual.
