Crane Quick Guides 117 Section - 16
Operator’s - Manual # 99906363
Light Operations
LIGHT OPERATIONS
SOFT TOGGLE TOGGLE DESCRIPTION
1 Up All Body Lights
1 Down Boom Tip Lights
2 Up Left Side Flood Lights
2 Down Right Side Flood Lights
3 Up Front Flood Lights
3 Down Rear Flood Lights
4 Up Left Compartment Lights
4 Down Right Compartment Lights
1
2 3
4
6
This chart is to be used as a “quick reference” guide only.
It should not be substituted for a thorough review of the manual.
