Radio Remote 77 Section - 13
Operator’s - Manual # 99906363
Handheld Remote (70735198)
ITEM DESCRIPTION SPECIFICATIONS
Power
Vin +4.0 to +6.0 VDC
Batteries Four “AA” cell
Battery Life 30 hours
Low V Shutdown 4.0 VDC
Auto-shutdown 10 min. of button inactivity
Environment
Operating Temp
–20° C to 55° C
(–4° F to 131° F)
Storage Temp
–40° C to 55° C
(–40° F to 131° F)
Humidity 0 to 100%
Radio
Frequency 2405–2480 MHz
RF Power 100 mW (max.)
License None required
Modulation DSSS
Antenna Internal
Enclosure
Dimensions mm: 230.6 x 133.9 x 146.9; inch: 9.1 x 5.3 x 5.8
Total Weight 2.2 lbs
Durability High Impact Polymer case
Faceplate Aluminum or Polycarbonate
Control Switches
Toggle Six 3-position spring return to center
Trigger Spring release
Mushroom Professional Stop
Display LCD 536 x 336 pixel resolution
70735198 SPARE PARTS
PART NO. DESCRIPTION
71415460 MAGNET-TELE RAD REM TRANS W SCREW CERVIS
77040857 BUTTON E-STOP S4 REMOTE
77040858 HOLDER BATTERY S4 REMOTE
77040859 CAP BATTERY S4 REMOTE
77040860 SWITCH TOGGLE S4 REMOTE
77040861 CAP M12 TETHER S4 REMOTE
Tethered Cable
Connector Port
Battery
Compartment
Trigger
