IMT CMD.CTRL - Body-Fault Tables

Body Codes 135 Section - 20
Operator’s - Manual # 99906363
Body—Fault Tables
HELP
MESSAGE DTC
STOP
ICON
WARN
ICON ACTION TRIGGER LATCH
Power Cycle 0 OFF OFF · No restrictions
This Help Message is issued at
each power-up. This serves to
indicate which messages have
been recorded in the failure log
since the last power-up event.
Unlatched
Everything Ok 1 OFF OFF · No restrictions No Faults are active. Unlatched
Battery Voltage
Too Low
210 ON ON
• Stabilizer =
PREVENTED
System voltage is < 9.0 volts for
5000 mS.
Unlatched
• Crane Enable =
PREVENTED
• Compressor =
PREVENTED
• PTO =
PREVENTED
• Compartment
Fans =
PREVENTED
• Horn =
PREVENTED
• Lights =
PREVENTED
Battery Voltage
Too High
211 ON
ON with
Pop UP
• Stabilizer =
PREVENTED
System voltage > 18 volts for
5000 mS.
Unlatched
• Crane Enable =
PREVENTED
• Compressor =
PREVENTED
• PTO =
PREVENTED
• Engine
Start/Stop =
PREVENTED
• Compartment
Fans =
PREVENTED
• Horn =
PREVENTED
• Lights =
PREVENTED
PTO - Active At
Power Up
220 OFF ON • No restrictions
PTO on input (J3E2) is active at
power up.
Latched
Horn – Open
Circuit
231 OFF ON • No restrictions
Open Circuit detected on Horn
output and Crane Power Enable
is O󰀨.
Unlatched
Horn – Short To
Battery
232 OFF ON • No restrictions
Short to Battery was detected on
Horn Output
Unlatched
Horn – Short To
Ground
233 OFF ON • Disable Output
Short to Ground was detected on
Horn Output
Latched
Boom Tip Light –
Open Circuit
234 OFF ON • No restrictions
Open Circuit detected on Boom
Tip Light Output
Unlatched
Vehicle must be congured to
have Boom Tip Lights installed
and not congured as a
Hydraulic 2nd Gen Crane.
