IMT CMD.CTRL - Page 154

Body Codes 136 Section - 20
Operator’s - Manual # 99906363
HELP
MESSAGE DTC
STOP
ICON
WARN
ICON ACTION TRIGGER LATCH
Boom Tip Light –
Short To Battery
235 OFF ON • No restrictions
Short to Battery detected on
Boom Tip Light Output
Unlatched
Vehicle must be congured to
have Boom Tip Lights installed.
Boom Tip Light –
Short To Ground
236 OFF ON • Disable Output
Short to Ground was detected on
Boom Tip Light Output
Latched
Vehicle must be congured to
have Boom Tip Lights installed.
Hydraulic Bypass
Valve – Open
Circuit
237 OFF ON • No restrictions
Open Circuit detected on
Hydraulic Bypass Valve
Unlatched
Vehicle must have at least one
Stabilizer installed to detect this
fault.
Hydraulic Bypass
Valve – Short To
Battery
238 OFF ON
• Stabilizer =
PREVENTED
Short to Battery detected on
Hydraulic Bypass Valve
Unlatched
Hydraulic Bypass
Valve – Short To
Ground
239 OFF ON • Disable Output
Short to Ground was detected on
Hydraulic Bypass Valve Output
Latched
Compressor
Relay – Open
Circuit
2310 OFF ON • No restrictions
Open Circuit detected on
Compressor Output.
Unlatched
Vehicle must be congured to
have the compressor installed
and Crane Power Enable is O󰀨.
Compressor
Relay – Short To
Battery
2311 OFF ON • No restrictions
Short to Battery detected on
Compressor Output.
Unlatched
Vehicle must be congured to
have the compressor installed.
Compressor
Relay – Short To
Ground
2312 OFF ON • Disable Output
Short to Ground was detected on
Compressor Output.
Latched
Vehicle must be congured to
have the compressor installed.
Compartment Fan
– Open Circuit
2313 OFF ON • No restrictions
Open Circuit detected on
Compartment Fan Output.
Unlatched
Vehicle must be congured to
have the compartment fans
installed.
Compartment
Fan – Short To
Battery
2314 OFF ON • No restrictions
Short to Battery detected on
Compartment Fan Output.
Unlatched
Vehicle must be congured to
have the compartment fans
installed.
Compartment
Fan – Short To
Ground
2315 OFF ON • Disable Output
Short to Ground was detected on
Compartment Fan Output.
Latched
Vehicle must be congured to
have the compartment fans
installed.
Crane
Compartment
Light – Open
Circuit
2316 OFF ON • No restrictions
Open Circuit detected on Crane
Compartment Light Output
Unlatched
Crane
Compartment
Light – Short To
Battery
2317 OFF ON • No restrictions
Short to Battery detected on
Crane Compartment Light Output
Unlatched
Crane
Compartment
Light – Short To
Ground
2318 OFF ON • Disable Output
Short to Ground was detected on
Crane Compartment Light Output
Latched
