IMT CMD.CTRL - Page 155

Body Codes 137 Section - 20
Operator’s - Manual # 99906363
HELP
MESSAGE DTC
STOP
ICON
WARN
ICON ACTION TRIGGER LATCH
Crane Enable
Relay – Open
Circuit
2319 OFF ON • No restrictions
Open Circuit detected on Crane
Enable Relay Output
Unlatched
Crane Enable
Relay – Short To
Battery
2320 OFF ON • No restrictions
Short to Battery detected on
Crane Enable Relay Output
Unlatched
Crane Enable
Relay – Short To
Ground
2321 OFF ON • Disable Output
Short to Ground was detected on
Crane Enable Relay Output
Latched
Left Rear
Stabilizer Down –
Open Circuit
2322 OFF ON • No restrictions
Open Circuit detected on Left
Rear Stabilizer Down Output.
Unlatched
Vehicle must be congured
to have the left rear stabilizer
installed.
Left Rear
Stabilizer Down –
Short To Battery
2323 OFF ON
• Disable Bypass
Valve
Short to Battery detected on Left
Rear Stabilizer Down Output.
Unlatched
Vehicle must be congured
to have the left rear stabilizer
installed.
Left Rear
Stabilizer Down–
Short To Ground
2324 OFF ON • Disable Output
Short to Ground was detected on
Left Rear Stabilizer Down Output.
Latched
Vehicle must be congured
to have the left rear stabilizer
installed.
Left Rear
Stabilizer Up –
Open Circuit
2325 OFF ON • No restrictions
Open Circuit detected on Left
Rear Stabilizer Up Output.
Unlatched
Vehicle must be congured
to have the left rear stabilizer
installed.
Left Rear
Stabilizer Up –
Short To Battery
2326 OFF ON
• Disable Bypass
Valve
Short to Battery detected on Left
Rear Stabilizer Up Output.
Unlatched
Vehicle must be congured
to have the left rear stabilizer
installed.
Left Rear
Stabilizer Up –
Short To Ground
2327 OFF ON • Disable Output
Short to Ground was detected on
Left Rear Stabilizer Up Output.
Latched
Vehicle must be congured
to have the left rear stabilizer
installed.
Left Rear
Stabilizer Extend
– Open Circuit
2328 OFF ON • No restrictions
Open Circuit detected on Left
Rear Stabilizer Extend Output.
Unlatched
Vehicle must be congured to
have an extendable left rear
stabilizer installed.
Left Rear
Stabilizer Extend
– Short To Battery
2329 OFF ON
• Disable Bypass
Valve
Short to Battery detected on Left
Rear Stabilizer Extend Output.
Unlatched
Vehicle must be congured to
have an extendable left rear
stabilizer installed.
Left Rear
Stabilizer
Extend – Short To
Ground
2330 OFF ON • Disable Output
Short to Ground was detected
on Left Rear Stabilizer Extend
Output.
Latched
Vehicle must be congured to
have an extendable left rear
stabilizer installed.
Left Rear
Stabilizer
Retract – Open
Circuit
2331 OFF ON • No restrictions
Open Circuit detected on Left
Rear Stabilizer Retract Output.
Unlatched
Vehicle must be congured to
have an extendable left rear
stabilizer installed.
