Crane Quick Guides 120 Section - 16
Operator’s - Manual # 99906363
Compressor
COMPRESSOR
1
2 3
4
☛
This is an example. Actual compressor functionality will depend on the system
configuration. Compressor will only run when the air tank pressure level is
below set point.
Compressor Steps:
1. Engage E-Brake and start the engine.
2. Engage PTO.
3. Power ON Remote - RFF Toggle UP and HOLD for one half of a second.
4. Click the LFF toggle UP to turn the Compressor ON and OFF.
RFF
LFF
RFF
Toggle
LFF
Toggle
When Auto PTO is
configured, the
Pop Up Screen
can be acknowledge
with Soft Toggle 2 UP.
9
This chart is to be used as a “quick reference” guide only.
It should not be substituted for a thorough review of the manual.
