Crane Glossary Icons 99 Section - 14
Operator’s - Manual # 99906363
ICONS DESCRIPTION
Indicates Switch Screens
Indicates Horn
Indicates Engine Speed
Indicates Boom Tip Light
Indicates Boom Tip Light ON / OFF
Indicates all Body Lights
Indicates Left Compartment Lights
Indidcates Right Compartment Lights
Indicates Right-Side Flood Lights
Indicates Left-Side Flood Lights
Indicates Front Flood Lights
Indicates Rear Flood Lights
Boom Rotate CW / CCW
Boom Extend / Retract
To Next Page
