IS810N-INT Series Servo System User Manual (Brief)Chapter 4 Wiring
b) OC mode

When the internal 24 V power supply of the servo drive is used:
Wrong connection: Pin COM- is not connected, which causes an open circuit.
Servo driveHost controller
Servo drive
+24 V power supply
Host controller
Servo driveHost controller
+24 V power supply
+24 V power
supply
