IS810N-INT Series Servo System User Manual (Brief) Chapter 2 Product Information
- 26 -
Model
Rated
Output
(kW)*1
Rated
Torque
(N•m)
Maximum
Torque
(N•m)
Rated
Current
(A)
Maximum
Current
(Arms)
Rated
Speed
(RPM)
Maximum
Speed
(RPM)
Torque
Parameter
(N•m/A)
Rotor Load
Inertia
(10-4
kg•m2)
Voltage
(V)
ISMH3 (Vn = 1500 RPM, Vmax = 3000 RPM)
ISMH3-85B15CB-
***Y
0.85 5.39 13.5 6.60 16.50
1500 3000
0.9
13
(15.5)
220
ISMH3-13C15CB-
***Y
1.3 8.34 20.85 10.00 25.00 0.9
19.3
(21.8)
ISMH3-85B15CD-
***Y
0.85 5.39 13.5 3.30 8.25 1.75
13
(15.5)
380
ISMH3-13C15CD-
***Y
1.3 8.34 20.85 5.00 12.50 1.78
19.3
(21.8)
ISMH3-18C15CD-
***Y
1.8 11.5 28.75 6.60 16.50 1.8
25.5
(28)
ISMH3-29C15CD-
***Z
2.9 18.6 37.2 11.90 28.00 1.7
55
(57.2)
ISMH3-44C15CD-
***Z
4.4 28.4 71.1 16.50 40.50 1.93
88.9
(90.8)
ISMH3-55C15CD-
***Z
5.5 35.0 87.6 20.85 52.00 1.80
107
(109.5)
ISMH3-75C15CD-
***Z
7.5 48.0 119 25.70 65.00 1.92
141
(143.1)
ISMH4 (Vn = 3000 Rpm, Vmax = 6000 RPM)
ISMH4-40B30CB-
***Z
0.4 1.27 3.82 2.80 10.10
3000 6000
0.50
0.653
(0.667)
220
ISMH4-75B30CB-
***Z
0.75 2.39 7.16 4.80 15.10 0.57
2.02
(2.033)
Note 1: The motor with an oil seal must be derated by 10% during use.
Note 2: Parameters in () are for a motor with a brake.
The parameter values in the preceding table are applicable when the motor works together
with the Inovance servo drive and the armature coil temperature is 20°C.
The preceding table shows the characteristic parameters of the motor after a heatsink below
is installed for the motor.
ISMH1/ISMH4: 250 × 250 × 6 mm (aluminum)
ISMH2-10C to 25C: 300 × 300 × 12mm (aluminum)
ISMH2-30C to 50C: 400 × 400 × 20mm (aluminum)
ISMH3-85B to 18C: 400 × 400 × 20mm (iron)
ISMH3-29C to 75C: 360 × 360 × 5mm (double aluminum plate)
3) Motor Overload Characteristics
Load Ratio (%) Running Time (s) Load Ratio (%) Running Time (s)
120 230 200 10
130 80 210 8.5
140 40 220 7
150 30 230 6
160 20 240 5.5
170 17 250 5
180 15 300 3
190 12
