Inovance IS810N-INT Series User Manual

IS810N-INT Series Servo System User Manual (Brief) Appendix 1 List of Object Groups
- 270 -
Parameter group
Name
Option
Description
Setting Range Default Min. Unit Width
Change
method
Effective
Way
Hexadecimal Decimal
Group Index Parameter
2003
04h H03-03
DI1 terminal
logic selection
0: Indicates
that low level
is valid
1: Indicates
that high level
is valid
2: Indicates
that the rising
edge is valid
3: Indicates
that the falling
edge is valid
4: Indicates
that the rising
and falling
edges are
valid
0 to 4 0 1 16 bits
During
running
Upon stop
05h H03-04
DI2 terminal
function
selection
0 to 39
Please refer to
the description
of the H03-02
option
0 to 65535 0 1 16 bits
During
running
Upon stop
06h H03-05
DI2 terminal
logic selection
0 to 4
Please refer to
the description
of the H03-03
option.
0 to 4 0 1 16 bits
During
running
Upon stop
07h H03-06
DI3 terminal
function
selection
(0 to 39)
Please refer to
the description
of the H03-02
option
0 to 65535 0 1 16 bits
During
running
Upon stop
08h H03-07
DI3 terminal
logic selection
0 to 4
Please refer to
the description
of the H03-03
option.
0 to 4 0 1 16 bits
During
running
Upon stop
09h H03-08
DI4 terminal
function
selection
0 to 39
Please refer to
the description
of the H03-02
option
0 to 65535 0 1 16 bits
During
running
Upon stop
0Ah H03-09
DI4 terminal
logic selection
0 to 4
Please refer to
the description
of the H03-03
option.
0 to 4 0 1 16 bits
During
running
Upon stop
0Bh H03-10
DI5 terminal
function
selection
0 to 39
Please refer to
the description
of the H03-02
option
0 to 65535 0 1 16 bits
During
running
Upon stop
0Ch H03-11
DI5 terminal
logic selection
0 to 4
Please refer to
the description
of the H03-03
option.
0 to 4 0 1 16 bits
During
running
Upon stop
