IS810N-INT Series Servo System User Manual (Brief)Appendix 1 List of Object Groups
- 271 -
Parameter group
Name
Option
Description
Setting Range Default Min. Unit Width
Change
method
Effective
Way
Hexadecimal Decimal
Group Index Parameter
2003
0Dh H03-12
DI6 terminal
function
selection
0 to 39
Please refer to
the description
of the H03-02
option
0 to 65535 0 1 16 bits
During
running
Upon stop
0Eh H03-13
DI6 terminal
logic selection
0 to 4
Please refer to
the description
of the H03-03
option.
0 to 4 0 1 16 bits
During
running
Upon stop
0Fh H03-14
DI7 terminal
function
selection
0 to 39
Please refer to
the description
of the H03-02
option
0 to 65535 0 1 16 bits
During
running
Upon stop
10h H03-15
DI7 terminal
logic selection
0 to 4
Please refer to
the description
of the H03-03
option.
0 to 4 0 1 16 bits
During
running
Upon stop
11h H03-16
DI8 terminal
function
selection
(0 to 39)
Please refer to
the description
of the H03-02
option
0 to 65535 0 1 16 bits
During
running
Upon stop
12h H03-17
DI8 terminal
logic selection
0 to 4
Please refer to
the description
of the H03-03
option.
0 to 4 0 1 16 bits
During
running
Upon stop
2004h/H04 Terminal output parameters
2004 01h H04-00
DO1 terminal
function
selection
Description:
It consists of
three digits,
the rst one
(from left to
right) indicates
the axis
number, and
the last two
digits indicate
the terminal
function. The
last two digits
are dened as
follows:
0: No
denition
01: Servo
ready
02: Motor
rotation
10: Warning
11: Fault
0 to 65535 0 1 16 bits
During
running
Upon stop
