Inovance IS810N-INT Series - Page 282

IS810N-INT Series Servo System User Manual (Brief) Appendix 1 List of Object Groups
- 282 -
Parameter group
Name
Option
Description
Setting Range Default Min. Unit Width
Change
method
Effective
Way
Hexadecimal Decimal
Group Index Parameter
200B
1Fh H0B-30
System failure
information
given by
FPGA
- 0 to 0xFFFF 0 1 16 bits - -
20h H0B-31
Encoding
internal fault
information
- 0 to 0xFFFF 0 1 16 bits - -
22h H0B-33 Fault record - 0 to 9 0 1 16 bits
During
running
Immediate
23h H0B-34
Fault code of
the selected
fault record
- 0 to 0xFFFF 0 1 16 bits - -
24h H0B-35
Time stamp
upon
displayed
fault
-
0 to
4294967295
0 0.1s 32 bits - -
26h H0B-37
Motor
speed upon
displayed
fault
- -9999 to 9999 0 1 RPM 16 bits - -
27h H0B-38
Motor
phase U
current upon
displayed
fault
-
-32768 to
32767
0 0.01 A 16 bits - -
28h H0B-39
Motor
phase V
current upon
displayed
fault
-
-32768 to
32767
0 0.01 A 16 bits - -
29h H0B-40
Bus voltage
upon
displayed
fault
- 0 to 65535 0 0.1 V 16 bits - -
2Ah H0B-41
Input terminal
state upon
displayed
fault
- 0 to 0x00FF 0 1 16 bits - -
2Ch H0B-43
Output
terminal
state upon
displayed
fault
- 0 to 0x0002 0 1 16 bits - -
2Eh H0B-45
Internal fault
code
- 0 to 0xFFFF 0 1 16 bits - -
2Fh H0B-46
Absolute
encoder error
information
given by
FPGA when
the fault is
selected
- 0 to 0xFFFF 0 1 16 bits - -
30h H0B-47
System status
information
given by
FPGA when
the fault is
selected
- 0 to 0xFFFF 0 1 16 bits - -
31h H0B-48
System failure
information
given by
FPGA when
the fault is
selected
- 0 to 0xFFFF 0 1 16 bits - -
