CEAST 9340 - Instructions for Use and Maintenance 7510.000MN1r ed. 1 rev. 1 - Page 103
8.10 CARRY OUT TEST
Authorized Personnel: Operator
8.10.1 OPERATING SEQUENCE OF AN INSTRUMENTED TEST
a) Open the door of the test chamber;
b) Place a specimen on the support.
c) Close the door of the test chamber;
d) Run an instrumented test from the software of the PC. When the trigger bar starts to
move, press two times the “Start” key on the keypad of the instrument.
Note: the instructions on how to run the test are described in the “CeastVIEW
VisualIMPACT Instruction Manual” supplied with the software.
e) The instrument carries out test and the DAS (data acquisition system) acquires the
signal coming from the instrumented striker during the impact;
f) At the end of test press the “Back” key on the keypad of the instrument to return to
the “Main menu” (Vid. 1) ready to start a next test.
X
X
X
X
Note: to adjust the height of the adjustable height stand follow these instructions:
1) Enter the test parameters set through the keypad of the instrument control
box or sending it to the instrument through the VisualIMPACT software;
2) Without placing a specimen on the specimen fixture, move the striker to the
impact height H = 0 (for the movement use the proper keys on the keypad of
the instrument control box or sending the command to the instrument through
the VisualIMPACT software);
3) Place a specimen on the specimen fixture and adjust the height of the ad-
justable height stand until the upper surface of the specimen skims the striker
head;
4) Bring the instrument at HOME position using the proper key.
5) Carry out test.
X
X
