Instron CEAST 9340 - REPLACEMENT of the STRIKERS HEADS (Interchangeable Head Type)

Page 82 - CEAST 9340 - Instructions for Use and Maintenance 7510.000MN1r ed. 1 rev. 1
8.6.7 REPLACEMENT OF THE STRIKER’S HEADS (interchangeable head type)
Authorized Personnel: Operator
Fig. 2 - Fixture to align the Charpy and Izod heads to the striker body
(optional device)
Screw
Heads
alignment
template
Base
Striker
centering
plate
Pin
Fig. 3 - Striker with Charpy head installed
on CEAST 9340
Fig. 4 - Striker with Izod head installed
on CEAST 9340
Spacer
Instrumented
striker body
Ring nut
Signal cable
Hemispherical head
(dia. 12.7 mm)
Head for Charpy test
Head for Izod test
Fig. 1 - Instrumented striker with interchangeable heads
Note: for the Strikers Technical Features refer to the Appendix B at the end of
this document.
Charpy
Izod (with
pivoting
loader)
Izod
(with fixed height stand and
adjustable height stand)
