Instron CEAST 9340 - Loader Upgrade; Firmware Upgrade

Page 114 - CEAST 9340 - Instructions for Use and Maintenance 7510.000MN1r ed. 1 rev. 1
X
Note: before starting the loader upgrade procedure check that the instrument is switched-
off.
X
X
X
X
a) Click on “File Selection” button and select from the list the file containing the loader
update.
b) Click on “Start Transfer” button and wait until the message “Waiting ...” appears in
the “Operation” field.
c) Switch-on the instrument and wait until the loading procedure ends. When the op-
eration ends the program visualizes the transfer results in the “Operation” field and
“Status” field:
9.4.3.1 LOADER UPGRADE
9.4.3.2 FIRMWARE UPGRADE
WARNING ! - This procedure must be carried out only after explicit authorization of ITW
Test and Measurement Italia S.r.l. - INSTRON CEAST Division.
Operation:starting ...
Status: seq err ...
Operation:completed
Status: flash programmed OK
__
>
__
>
a) Click on “File Selection” button and select from the list the file containing the firm-
ware update.
b) Click on “Start Transfer” button and wait until the message “Waiting ...” appears into
the “Operation” field.
c) Switch-on the instrument and wait until the loading procedure ends. When the op-
eration ends the program visualizes the transfer results in the “Status” field:
(Transfer Failed / End of File).
Note: before starting the loader upgrade procedure check that the instrument is switched-
off.
X
d) Click on “File Selection” button and select from the list the file containing the loader.
e) Click on “Start Transfer” button and wait until the “Sync” button becomes highlighted
(function enabled).
f) Click on “Sync” button and wait until the loading procedure ends.
When the operation ends the program visualizes the transfer result in the “Opera-
tion” field (completed).
- If the loading fails, leave the instrument on and contact immediately the ITW Test
and Measurement Italia S.r.l. - INSTRON CEAST Division Service.
- If the loading is completed switch-off the instrument and click on “Close” button to
close the window (Fig. 4).
X
X
X
X
X
Note: to avoid problems during the loader upgrade procedure it is essential to maintain
the instrument switched-on.
