The programming of the tests is done by typing in the parameters using the keyboard in
the order that they are shown on the display.
After the test cycle is started, the program performs the measurements requested, ac-
quires the data, elaborates it, and automatically supplies the results.
The results obtained can be seen in real time on display.
Note: to facilitate the understanding of the program structure there follows a flowchart
showing its functions in hierarchical order. Each block is identified with the writing
Vid. (Screen) and a progressive number, XXX, that follows the order of appear-
ance on the screen of the display. This order is followed in order to present the
figures during the description of the program.
8.4.2 PROGRAM
