CEAST 9340 - Instructions for Use and Maintenance 7510.000MN1r ed. 1 rev. 1 - Page 47

Vid. 0 - Initial Screen

CEAST 9340 CEAST 9340

CEAST 9340

Ver. X.XX Ver. X.XX

Ver. X.XX

S.N. XXXXX S.N. XXXXX

S.N. XXXXX

Vid. 00 - CEAST 9340 Startup Screen

press START for press START for

press START for

CEAST 9340 startup CEAST 9340 startup

CEAST 9340 startup

8.5 PROGRAM START - UP

The program is automatically started when the Main switch is “ON” and it performs the

following operations

• Shows, temporarily, on the display the introduction of the program (see Vid. 0) where the

following information are indicated

: (1) name of the instrument, (2) the firmware version

resident in memory and (3) the serial number.

• After few seconds the screen changes from vid. 0 to vid. 00 visualizing the message

“press START for CEAST 9340 startup”.

Note: before pressing the START key check that the POWER ON button is lit.

• When the operator press the START key the program performs the following operations

and at the end it loads the parameters relative to the last test performed (only if it has

been previously stored on the instrument memory) and it visualizes the main menu (see

Vid. 1).

• Check of safety thermostat operation (for instrument equipped with environmental

chamber only);

• Check of temperature sensor operation (Pt100 ohm type) that measure the tempera-

ture in the chamber (for instrument equipped with environmental chamber only);

• Initialization of specimen clamping system;

• Initialization of environmental chamber shutter (optional).

Note: at the start the instrument the “Password” is set to the previous access level (before

switching it off).
