Page 160 - CEAST 9340 - Instructions for Use and Maintenance 7510.000MN1r ed. 1 rev. 1
APPENDIX C - TOOLING FOR TENSILE IMPACT TEST ONLY
TENSILE - IMPACT TESTING
STANDARD SPECIMEN
TYPE
CLAMPING FOR RIGID
SPECIMENS AND FILMS
CALIBRATED
FREE
TENSILE
GRIP
PIEZO-
ELECTRIC
FORCE
SENSOR
STRIKER
Adapter Knurled
Plate
Gripping
Adapter
Specimen
Holding
Fixture
ISO 8256
Method A
1and 3 7520.255 X X
for spec.
thickness
3 mm
X For rigid spec.
from 7520.271
to 7520.278
7520.251
or
7520.252
7510.260
X
for spec.
thickness
4 mm
XX
for films
For films
from 7520.281
to 7520.283
2 and 4 7520.256 X X
for spec.
thickness
3 mm
X For rigid spec.
from 7520.271
to 7520.278
X
for spec.
thickness
4 mm
XX
for films
For films
from 7520.281
to 7520.283
5 7520.257 - - - For rigid spec.
from 7520.271
to 7520.278.
