Page 56 - CEAST 9340 - Instructions for Use and Maintenance 7510.000MN1r ed. 1 rev. 1

8.5.7 RESULTS

V:xx.x m/s Vr:xx.x m/sV:xx.x m/s Vr:xx.x m/s

V:xx.x m/s Vr:xx.x m/s

CL AR +xx °CCL AR +xx °C

CL AR +xx °C

xxxx mm xx.x m/sxxxx mm xx.x m/s

xxxx mm xx.x m/s

M:xx.x kg E:xxxx JM:xx.x kg E:xxxx J

M:xx.x kg E:xxxx J

8.5.6 SAVE PARAMETERS

Vid. 1.4 - “Save Parameters“

01 yyyyyyyyyyyyyyy01 yyyyyyyyyyyyyyy

01 yyyyyyyyyyyyyyy

02 yyyyyyyyyyyyyyy02 yyyyyyyyyyyyyyy

02 yyyyyyyyyyyyyyy

03 yyyyyyyyyyyyyyy03 yyyyyyyyyyyyyyy

03 yyyyyyyyyyyyyyy

04 yyyyyyyyyyyyyyy04 yyyyyyyyyyyyyyy

04 yyyyyyyyyyyyyyy

05 yyyyyyyyyyyyyyy05 yyyyyyyyyyyyyyy

05 yyyyyyyyyyyyyyy

.. ....... .....

.. .....

25 yyyyyyyyyyyyyyy25 yyyyyyyyyyyyyyy

25 yyyyyyyyyyyyyyy

The menu “Save Parameters” allows to save a group of parameters that has been

previously modified.

1) The group position is selected by the user through the cursor “>” and saved with the

ENTER

key.

Note: the program overwrites the current set to the selected group.

After the save the program return to the “Main menu”.

This menu visualizes the values related to the last performed test (if performed)

1) “V”: velocity of the striker impact measured from the optical detector.

2) “Vr”: velocity of the striker rebound measured from the optical detector

3) “CL”: it is visualized only if the “clamping” option is configured and activated.

4) “AR”: it is visualized only if the “antirebound” option is configured and activated.

4) “+xx °C”: this field shows the test temperature (only if the environmental chamber is

configured and the conditioning is activated).

5) “xxxx mm”: it is the drop height value (parameter “H”, see Vid. 1.3 a).

6) “xx.x m/s”: it is the expected velocity.

7) “M: xx.x kg”: it is the dropping mass.

8) “E: xxxx J”: it is the potential energy.

Vid. 1.5 - Menu “Results“
