CEAST 9340 - Instructions for Use and Maintenance 7510.000MN1r ed. 1 rev. 1 - Page 55
Drop
Height
Nominal
Impact
Plane
Drop
Height
Impact
Offset
Specimen
Tickness
Sketches referred to the steps: 11) Drop Height, 14) Specimen Thickness and 15) Impact Offset
Fixed height
stand
Adjustable
height stand
Note: all the parameters are shown on two rows:
• First row: name of the parameter.
• Second row: value (modifiable) and unit of measure (not modifiable).
Note: the “minimum and maximum limits” of the parameters attributes and the “unit of
measure” of each parameter are indicated in the table “Test Parameters” on the
next page.
Note: the instructions for typing the parameters are shown in chapters 8.4.2.
Note: for further technical data related to the “striker antirebound system” make refer-
ence to the “Appendix H“.
Test Parameters
Measure
Units
Input
Format
Limits
Min. Max.
Temperature
[°C]
-50 100
+/-xx
[kg]
[mm]
[m/s]
[mm]
[mm]
[mm]
Mass
Velocity
Striker Length
Specimen Thickness
Impact Offset
Drop Height
0.9 40
30 1100
0,77
4.64
239
370
0
25
- 120 + 100
xxxxx
xx.xx
xxx
xx.x
+/-xx
xx.xx
