Page 54 - CEAST 9340 - Instructions for Use and Maintenance 7510.000MN1r ed. 1 rev. 1
Vid. 1.3 b - “Parameters (other)“
TEMPERATURETEMPERATURE
TEMPERATURETEMPERATURE
TEMPERATURE
[°C] [°C]
[°C] [°C]
[°C]
+XXX.XX+XXX.XX
+XXX.XX+XXX.XX
+XXX.XX
MASSMASS
MASSMASS
MASS
[Kg][Kg]
[Kg][Kg]
[Kg]
XX.XXX.X
XX.XXX.X
XX.X
DROP HEIGHTDROP HEIGHT
DROP HEIGHTDROP HEIGHT
DROP HEIGHT
[mm][mm]
[mm][mm]
[mm]
XXXXXX
XXXXXX
XXX
VELOCITYVELOCITY
VELOCITYVELOCITY
VELOCITY
[m/s][m/s]
[m/s][m/s]
[m/s]
XX.XXXX.XX
XX.XXXX.XX
XX.XX
ENERGYENERGY
ENERGYENERGY
ENERGY
[J][J]
[J][J]
[J]
XX.XXX.X
XX.XXX.X
XX.X
STRIKER LENGTHSTRIKER LENGTH
STRIKER LENGTHSTRIKER LENGTH
STRIKER LENGTH
[mm][mm]
[mm][mm]
[mm]
XXXXXX
XXXXXX
XXX
SPECIMEN OFFSETSPECIMEN OFFSET
SPECIMEN OFFSETSPECIMEN OFFSET
SPECIMEN OFFSET
[mm][mm]
[mm][mm]
[mm]
XX.X
XX.X
XX.XXX.X
XX.X
IMPACT OFFSETIMPACT OFFSET
IMPACT OFFSETIMPACT OFFSET
IMPACT OFFSET
[mm][mm]
[mm][mm]
[mm]
XXXXXX
XXXXXX
XXX
>
9
10
11
12
13
9) “Temperature”: is the test temperature to which the environmental chamber is cooled
(negative value) or heated (positive value).
Parameter shown only if the “Conditioning” parameter (see Vid. 1.3 a) is selected “Y”.
10) “Mass”: is the total mass used for the impact test. It is equal to the sum of the
following weights: striker, striker holder, striker extension (if installed) and additional
weights (if installed).
11) “Drop Height”: is the height from which the striker is released for the impact test.
Parameter shown only if the “Input H/V/E” parameter (see Vid. 1.3 a) is selected “H”.
12) “Velocity”: is the velocity at which the striker strikes the specimen.
Parameter shown only if the “Input H/V/E” parameter (see Vid. 1.3 a) is selected “V”.
13) “Energy”: is the energy at the impact.
Parameter shown only if the “Input H/V/E” parameter (see Vid. 1.3 a) is selected “E”.
14) “Striker Length”: is the length of the striker used for the tests plus the striker exten-
sion (if installed).
Note: if the entered striker length value is wrong, it can cause a wrong striker posi-
tioning with a consequent error when carry out test. Moreover it can cause a colli-
sion between the striker and lubricating system (if this last one is installed).
15) “Specimen Offset”: is the thickness of the specimen under test.
Parameter shown only if the “Support Type” parameter (see Vid. 1.3 a) is selected “F”.
16) “Impact Offset”: is the distance between the nominal impact plane and the speci-
men surface.
Parameter shown only if the “Support Type” parameter (see Vid. 1.3 a) is selected “V”.
14
15
16
