CEAST 9340 - Instructions for Use and Maintenance 7510.000MN1r ed. 1 rev. 1 - Page 121
10.2 LIST OF SPARE PARTS FOR TECHNICAL ASSISTANCE
In order to meet any need and to guarantee the possibility of continuous use for a long
time period, it is recommended to keep the following spare parts in stock:
10.2.1 CEAST 9340 CODE 7515.000 AND 7516.000
Nr Code Description
1 0200.764 Limit switch
2 0200.765 Actuator for limit switch
3 0201.897 Encoder
4 0206.233 Connector, female, for proximity switch
5 0206.236 Proximity switch
6 0303.028 External retaining ring 12 UNI 7434-75
7 0400.515 Bearing
8 0400.751 Chain, type 206/S1/2" X5/16" L=3213,1M
9 0400.752 Joint with spring for chain 206/S
10 0400.754 Bush GSM-7528-30 IGUS
11 0500.196 Clip, type 81.125 zinc plated spec
12 0500.310 Decelerator
13 0500.906 Wrench with doublenotch 3 mm SOUTHCO
14 0801.332 Small block for slot 0.0.026.18 ITEM (not shown in the figures)
15 0801.357 Small block for slot 0.0.428.76 ITEM (not shown in the figures)
16 0801.358 Section for coverage
17 0801.620 Sensor 1500.U PNEUMAX with LED and cable
18 0801.679 Sensor RS.UAC2 PNEUMAX (connector and cable)
19 7510.AF.07 Impact roller
20 7510.AG.20 Photocell with connector
21 7510.AH.05 Motor pinion gear
22 7510.AH.06 Upper pinion gear
23 7510.CA.04 Guiding plate for standard striker holder
24 7510.CB.03 Guiding plate for light striker holder
