CEAST 9340 - Instructions for Use and Maintenance 7510.000MN1r ed. 1 rev. 1 - Page 63
Vid. 1.7.3 - “Move to Height“
OFP/OFQi: show the specimen offset or impact offset set in the current parameters set.
LP: show the length of the striker used for the tests, plus the striker extension (if in-
stalled) set in the current parameters set.
Note: if the entered striker length value is wrong, it can cause a wrong striker posi-
tioning with a consequent error when carry out test. Moreover it can cause a colli-
sion between the striker and lubricating system (if this last one is installed).
Type Zt/Hc and Height: select and enter the chosen position of the crosshead (Zt se-
lected) or the striker edge (Hc selected).
Zt is referred to the distance between the lower end of the striker holder and the
upper surface of the turret base.
Hc is referred to the distance between the lower end of the striker and the impact
point, and it depends from the test parameters.
Press the
START
key to start the positioning or the
BACK
key to go back without carry out
the positioning.
8.5.18 MOVE TO HEIGHT
>
Vid. 1.7.4 - “Visualize Sensors“
CROSSHEAD HE CROSSHEAD HE
CROSSHEAD HE CROSSHEAD HE
CROSSHEAD HE
XXXX.XXXXX.X
XXXX.XXXXX.X
XXXX.X
SET. P. TEMP.SET. P. TEMP.
SET. P. TEMP.SET. P. TEMP.
SET. P. TEMP.
XX.X XX.X
XX.X XX.X
XX.X
MEASURED TEMP.XXX MEASURED TEMP.XXX
MEASURED TEMP.XXX MEASURED TEMP.XXX
MEASURED TEMP.XXX
Visualize in real time the values measured by sensors.
1) Absolute crosshead height [mm];
2) Temperature set [°C] (*);
3) Temperature measured [°C] in the environmental chamber (*).
(*): only with environmental chamber.
8.5.19 VISUALIZE SENSORS
>
OFP=X.XOFP=X.X
OFP=X.XOFP=X.X
OFP=X.X
LP=XXXLP=XXX
LP=XXXLP=XXX
LP=XXX
TYPE Zt/HcTYPE Zt/Hc
TYPE Zt/HcTYPE Zt/Hc
TYPE Zt/Hc
ZZ
ZZ
Z
HEIGHTHEIGHT
HEIGHTHEIGHT
HEIGHT
XXXXXX
XXXXXX
XXX
Press START or BACKPress START or BACK
Press START or BACKPress START or BACK
Press START or BACK
