Page 124 - CEAST 9340 - Instructions for Use and Maintenance 7510.000MN1r ed. 1 rev. 1
3
10.2.2 ENVIRONMENTAL CHAMBER 7510.011
CODE (OPTIONAL EXTRA FOR CEAST 9340 7515.000)
(ALREADY INSTALLED ON CEAST 9340 7516.000)
Nr Code Description
1 0201.075 Thermostat TC-RC DV +50 +350°C switch
2 0204.193 Temperature sensor, Pt 100 GEFRAN
3 0400.799 Clamp with rubber lever SOU C7-10
4 0500.666 Solenoid valve SCE 263 B206 LT 24V/50H
5 0800.808 Sensor clamp 1260.16.F
6
0800.957 Sensor RS.UAC.1 PNEUMAX
2
6
5
4
1
