CEAST 9340 - Instructions for Use and Maintenance 7510.000MN1r ed. 1 rev. 1 - Page 15
Instrument Code 7515.000 7516.000
Technical Data
Electric Power Supply
Voltage [V] - Phases - Frequency [Hz] 230 - Single phase - 50/60
Total installed power [W] 600
3200
Fuses see attached wiring diagrams
Earth path in accordance with local regulations
Pneumatic Air Supply (compressed air)
Pressure at instrument inlet [bar] 10 max.
Working pressure [bar] 5
Liquid Nitrogen Supply
Pressure at instrument inlet [bar] - 7 max.
Working pressure [bar] - 1.2
Consumption at - 40 °C [kg/h] - 4
Consumption to cool from 23 to - 40 °C [kg] - 6
Overall Dimensions
Instrument (W x D x H) [mm] see 1.2.1 Layout drawing
Inner Dimensions
Test chamber (W x D x H) [mm] 490 x 450 x 565 370 x 300 x 495
Connection see 1.2.1 Layout drawing
Weight
Instrument [kg] 340 400
Paint
Grey RAL 7035 - Fuchsia RAL 4006
