CEAST 9340 - Instructions for Use and Maintenance 7510.000MN1r ed. 1 rev. 1 - Page 153
Note:- For the electric/electronic parts pls. refer to the location list (capter 12. Wiring
diagram, sheet 17).
Pneumatic Diagram, page 1
Label Code Description Location
PN1 0801.605 On-Off valve (Off lockable) PANPOS
PN2 0801.391 Pressure reducer with filter PANPOS
PN3 0801.065 Pressure gauge PANPOS
PN4 0801.628 On-Off valve PNEU
CIL1 0801.619 Specimen clamping left cylinder TOW
CIL2 0801.619 Specimen clamping left cylinder TOW
CIL3 0801.622 Striker releasing device cylinder TOW
Pneumatic Diagram, page 2
Label Code Description Location
CIL4 0801.644 Antirebound option left cylinder TOW
CIL5 0801.644 Antirebound option right cylinder TOW
CIL6 0801.661 Chamber shutter cylinder
(Environmental chamber option)
TOW
