Page 166 - CEAST 9340 - Instructions for Use and Maintenance 7510.000MN1r ed. 1 rev. 1
INPUT LIST (2 of 2)
Input on
I/O board
Meaning when:
input open or to GND;
LED on board OFF;
State physics/ logic "1"
(readed from CPU/shown
on display)
Sensor type or contact
/Sensor position
Notes
9 EIN9 Antirebound system in
working position (out of
limit)
2 reed NA (one per each
pneumatic cylinder) /on
upper side of cylinder (in
rest position)
With Antirebound option ,
the contact is closed with
antirebound to the rest (out
of limit)
10 EIN10 Specimen jammed Reed NA/on the upper side
of the pneumatic cylinder
(jammed specimen
position)
The contact is closed with
clamping plate aloft
(specimen NOT clamped)
11 EIN11 Presence of striker Proximity PNP NC / on the
crosshead in front of
carriage
12 EIN12 Striker NOT hooked Reed NA/on the outside
surface of pneumatic
cylinder (in hooked position)
The contact is closed with
hook closed (hooked
carriage)
13 EIN13 Shutter of chamber NOT
closed
Reed NA/on the inside
surface of pneumatic
cylinder (closing)
The contact is closed with
shutter completely closed
14 EIN14 Shutter of chamber NOT
open
Reed NA/on the outside
surface of pneumatic
cylinder (opening)
The contact is closed with
shutter completely open
15EIN15------
16EIN16------
