Page 42 - CEAST 9340 - Instructions for Use and Maintenance 7510.000MN1r ed. 1 rev. 1
5) - Upper and lower limit switches for the automatic striker recovery system: they
intervene and stop the stroke of the striker lifter in the two directions of motion.
These components are located in the turret.
6) - ON-OFF valve: is used to close the compressed air inlet to the instrument and in
the mean time to discharge the pneumatic circuit of the instrument without discon-
nect the air delivery pipe.
When the on-off valve is in “Closed” position the knob can be padlocked. This solu-
tion ensures the maximum safety of the personnel during the maintenance inter-
ventions. This component is located rear the instrument.
7) - Pressure switch: it intervene and cut off the power to the instrument when the
pressure of the compressed air goes down below 5 bar.
