CEAST 9340 - Instructions for Use and Maintenance 7510.000MN1r ed. 1 rev. 1 - Page 77
STRIKER HOLDER (STANDARD TYPE) CONFIGURATION
Nr Description Weight [kg] Q.ty
1
Striker Holder 2.5 1
2
Striker see Appendix B 1
3
Mass 0.5 1
4
Mass 1 (each) 2
5
Mass 2 1
6
Mass 5 (each) 3
7
Mass (option) 5 (each) 3
STRIKER HOLDER (LIGHT TYPE) CONFIGURATION
Nr Description Weight [kg] Q.ty
1
Striker Holder 0.5 1
2
Striker see Appendix B 1
3
Mass 0.5 1
4
Mass 1 (each) 2
b) Install the combinable weights on the striker holder:
••
••
• Standard striker holder:
- Unscrew the ring nut by hand (Fig. 1);
- Lift and install one weight (Fig. 3) at a time on the striker holder until to
obtain the mass needed. The first weight must be engaged on the two
pins located on the striker holder. Each weight added subsequently must
be engaged on the pins of the underneath one;
Note: avoid unbalancing movements toward the operator during the weights
installation operation that can cause the accidental drop of the weights.
- Tighten strongly the ring nut against the upper weight by hand.
••
••
• Light striker holder:
- Separate each weight (Fig. 4) in two parts after removing the screw;
- Insert one part of the weight from the back of the striker holder through one
of the existing holes (Fig. 2).
Place the second part of the weight on the first one and fasten it with
screw;
- Install the remaining two weights if necessary.
X
ASSEMBLY
a) Open the front door granting access to the lifting system, using the special key
provided.
