a) Open the chamber door.
b) Place (with precaution) the stand in the chamber. Lift it manually of about 2 cm and
engage it on the centering hub. During this operation be careful do not damage the
signal cable of the piezoelectric force sensor.
c) Turn the stand (if necessary) and visually align the hole for the shoulder screw (Fig.
1B).
d) Tighten the shoulder screw.
e) Tighten the Allen screws.
f) Pass the signal cable with connector through the hole of the chamber (see arrow of
Fig. 1B). Verify that the cable which remain in the chamber is not stretched.
g) Fasten a screw with a notched washer on the signal cable insulator (Fig. 1 D and E)
making sure that the notch of the washer is aligned with the slot of the insulator.
h) Place the signal cable in the slot of the insulator and then insert the insulator free end
through the chamber wall.
i) Fasten the insulator to the chamber using the remaining screw and notched washer
(Fig. 1B, D and E) making sure that the notch of the washer is aligned with the slot of
the insulator and it does not turn from this position when you tighten the screw,
otherwise there is a risk to cut the signal cable.
j) Place the collecting box onto the base of the vice support stand (Fig. 2).
X
X
ASSEMBLY
