6. Troubleshooting
Error Message in
Maintenance
SPA Failure
mode
FBA Failure
mode
OBA Failure
mode
SPA State 105 or 124
Sequence 27 or 29, Error:
timeout
Rotation fails to
reach position
Error Message in
Maintenance
SPA Failure
mode
FBA Failure
mode
OBA Failure
mode
FBA State 42 Sequence 17
Error: low-level controller,
detail: scanner error. Spare
LP unable to
reach position
FBA State 3 Sequence 1
Error: timeout
CP not moving
at proper
velocity
FBA State 3 Sequence 1
Error: timeout
LP not moving at
proper velocity
FBA State 5 Sequence 2
Error: timeout
CP not moving
at proper
velocity
FBA State 9 Sequence 4
Error: timeout
LP not moving at
proper velocity
FBA State 42 Sequence
17Error: timeout, detail: N/A
CP not reaching
45 deg position
on tube
FBA State 42 Sequence 17
Error: timeout, detail: N/A
LP unable to
home
FBA State 42 Sequence 17
Error: timeout, detail: N/A
CP is not
homing
FBA State 42 Sequence 17
Error: timeout, detail: N/A
CP not moving
at proper
velocity
