IRIS iQ 200 Sprint User Manual

Iris Diagnostics, a Division of Iris International, Inc.
iQ
®
200 Sprint™ (2G) Automated Urine Microscopy Analyzer Service Manual 300-4949 Rev A 01/2005 6-9
6. Troubleshooting
Error Message in
Maintenance
SPA Failure
mode
FBA Failure
mode
OBA Failure
mode
SPA State 91 Sequence 25
Error: timeout
Spa vertical
motor failed to
home
SPA State 97 Sequence 25
Error: timeout
Air system
unable to reach
setpoint
SPA State 99 Sequence 26
Error: timeout, Detail: N/A
EP not homing
SPA State 100 Sequence 26,
Error: Low-level controller.
Detail: scanner error. Spare.
EP not reaching
45 deg on tube.
SPA State 100 Sequence 26,
Error: timeout
Vertical down to
test tube not
reaching to set
position
SPA State 103 Sequence 27,
Error: timeout
Vertical up
position fails to
reach
SPA State 104 Sequence 27,
Error: Low-level controller,
Detail: Scanner error spare
EP not reaching
to position
SPA State 106 Sequence 27,
Error: timeout
Rotation fails to
reach position
SPA State 107 Sequence 27,
Error: timeout
Vertical down
position fails to
reach up
position
SPA State 109 Sequence 27,
Error: timeout
Vertical up
position fails to
reach
SPA State 111 Sequence 27,
Error: timeout
Vertical up
position fails to
home
SPA State 113 Sequence 27,
Error: timeout
Rotation fails to
reach home
position
SPA State 116 or 135
Sequence 27 or 29, Error:
timeout
Air system
unable to reach
setpoint
SPA State 119 Sequence 28
Error: timeout, Detail: N/A
Rotation fails to
reach position
