Iris Diagnostics, a Division of Iris International, Inc.
iQ
®
200 Sprint™ (2G) Automated Urine Microscopy Analyzer Service Manual 300-4949 Rev A 01/2005 9-9
9. Preventive Maintenance
5. Replace the Tubing fitting assembly (PN#700-3895) between the
Specimen Filter and the PBV N.C. Port.
6. Replace the Tubing fitting assembly (PN#700-3807) between the
PBV Common Port and the Flow Cell cannula input.
a. Cut the old tube from the top of the flow cell and remove
this tube by pulling firmly from underneath the fluid in tube
detector. Remove the other portion by unscrewing it off
the top of the Flow Cell, use caution not to damage the
Flow Cell!
