Iris Diagnostics, a Division of Iris International, Inc.
iQ
®
200 Sprint™ (2G) Automated Urine Microscopy Analyzer Service Manual 300-4949 Rev A 01/2005 2-17
2. Installation Procedures
5. Connect the assembled bridge between the iQ200 sampler and the
load station. (see picture below)
6. Attach the load station cable to port 2 labeled “Load” on the Rear
Panel SIC (jumpers in.)
