Iris Diagnostics, a Division of Iris International, Inc.

200 Sprint™ (2G) Automated Urine Microscopy Analyzer Service Manual 300-4949 Rev A 01/2005 2-21

2. Installation Procedures

11. Install and secure the sensor cover to the base plate. (see picture

below)

12. Reinstall the right side cover. DO NOT install the bottom screw

located on the backside of the sampler cover.

13. Assemble the bridge (see picture below)

Load station bridge assembly

Note

position of

guide plate
