IRIS iQ 200 Sprint

Iris Diagnostics, a Division of Iris International, Inc.
iQ
®
200 Sprint™ (2G) Automated Urine Microscopy Analyzer Service Manual 300-4949 Rev A 01/2005 2-22
2. Installation Procedures
14. Connect the assembled bridge between the AX-4280 sampler and
the load station. (see picture below)
15. Adjust the leveling feet under the Load Station to assure a smooth
transfer of racks.
