JRC JMA-7710-6 User Manual

3
3 – 78
3.5
3.5.4 Displaying the Contour of the Shoreline ROM Card by JRC
This function is used to display and select depth and color of contour of JRC card.
Procedures
1. Press the
SUB
MENU
key to open the SUB MENU.
2. Press the
4
key to open the RADAR #4 menu.
3. Press the
9
and
3
key to open the CONTOUR menu.
4. Press the numeric keys (
1
to
9
) to select contour number.
5. Press the numeric key (
1
to
9
) pressed in procedure 4 again,
the depth of the contour number is selected.
Enter the depth of the contour number by using numeric key (
0
to
9
), and press the
ENT
key to confirm the setting.
6. Press the numeric key (
1
to
9
) pressed in procedure 4 again,
the color of the contour number is selected.
Press the same numeric key (
1
to
9
) to select color, and press
the
ENT
key to confirm the setting.
7. By procedure 4 to 6, the depth of contour of JRC card can be selected 8
patterns.
Exit
8. Press the
SUB
MENU
key.
CONTOUR
1. 10M OFF SKY GRN YEL PNK
2. 20M OFF WHT SKY BLU GRN
YEL PNK RED
3. 30M OFF WHT SKY
BLU GRN YEL PNK RED
4. 40M OFF WHT SKY
BLU GRN YEL PNK RED
5. 50M OFF WHT SKY
BLU GRN YEL PNK RED
6. 60M OFF WHT SKY
BLU GRN YEL PNK RED
7. 70M OFF WHT SKY
BLU GRN YEL PNK RED
8. 80M OFF WHT SKY
BLU GRN YEL PNK RED
9. OTHER OFF WHT SKY
BLU GRN YEL PNK RED
CONTOUR 0. PREV
