5 – 18
5
When a target under tracking or the own ship steers away from the course, or when the radar acquires
a new target, its vector may not reach the required accuracy until 3 minutes passes after the acquisition
or the change of course. Even 3 minutes later, the vector may include some errors depending on the
tracking condition.
5.5.1 Types of Data Readouts to be Displayed
Target Data
Target ID (TARGET) : ID of target being displayed.
True bearing (T BRG) : In units of 1°
Range (RNG) : In units of 0.1 NM
True course (T CSE) : In units of 1°
True speed (T SPD) : In units of 0.1 knot
Closes point of approach (CPA) : In units of 0.1 NM
Time to closest point of approach (TCPA) : In units of 1 minute
For the data reading target, the symbol “ ” and the ID are displayed to distinguish it
from other targets.
Note
● When the symbol whose numerical data have been displayed is not found on the
screen, the target is outside the screen (the display range).
5.5 Data Reading
Attention
To Next Page
