11.4 Display Unit NCD-3901-2
1) Structure: Desktop type
2) Outside dimensions: Approx. W400 × H658 × D795 (mm)
(However, the dimension of the handle is excluded from the width.)
3) Mass: Approx. 63 kg.
4) Display: Vertical 21-inch color CRT
5) Number of pixels: 1024 × 768
6) Display area: Approx. 405 × 305 (mm)
7) Color, gradation and brilliance
Radar video
Gradation: 16 (8 in radar trail display mode)
Video color: 1 (yellow, green, orange)
Brilliance control: 4 steps
Radar track
Gradation: 1
Video color: 1 (sky, white, green)
Brilliance control: 4 steps (simultaneous control with radar video)
Fixed marker/VRM/EBL
Video color: Cyan
Brilliance level: 4 steps
The following brilliance levels are simultaneously changed.
Letter/dial plane
Video color: White
Brilliance level: 4 steps
SHM/cursor
Video color: White
Brilliance level: 4 steps
8) Range/scale spacing: Range Scale spacing Number of rings
0.125nm 0.0625nm 2
0.25nm 0.125nm 2
0.5nm 0.25nm 2
0.75nm 0.25nm 3
1.5nm 0.25nm 6
3nm 0.5nm 6
6nm 1nm 6
12nm 2nm 6
24nm 4nm 6
32nm 8nm 4
48nm 8nm 6
96nm 16nm 6 (10kW only)
120nm 20nm 6 (25kW only)
