JRC JMA-7710-6 User Manual

8
8 – 50
8.5
8.5.7.2 Adjusting Video and Chart Position by Entering Adjustment Value
(R+P and Plotter Modes)
Procedures
1. Follow procedures 1 and 2 in subsection 8.5.7.1 to open the INIT SET #3
menu.
2. Press the
2
key to select "SHIFT COAST LINE #2".
3. Press the
2
key or
ENT
key, enter an adjustment value for N (north
latitude) using numeric keys (
0
to
9
) and press the
ENT
key.
4. Enter an adjustment value for E (east longitude) using numeric keys
(
0
to
9
) and press the
ENT
key.
(Use the key for selecting the north latitade, south latitude, east
longitude or west longitud.)
Cancellation
1. Follow procedures 1 and 2 above to select "SHIFT COAST LINE #2".
2. Press the
2
key, enter "0" to an adjustment value for N using the
0
key and press the
ENT
key.
3. Enter "0" to an adjustment value for E using the
0
key and press the
ENT
key.
This cancels position adjustment.
Exit
5. Press the
SUB
MENU
key.
Position adjustment by entering adjustment values is enabled in the R+P and plotter
modes.
Init set #3
1. SHIFT COAST LINE #1 SETTING DELETE
2. SHIFT COAST LINE #2 N 0.000’
E 0.000’
3. LAT ／ LON CORRECTION N 0.000’
E 0.000’
4. CHART CENTER POSITION N 0˚ 00.000’
E 0˚ 00.000’
5. DATE ／ TIME
OFF UTC LOCAL
6.
INIT
SET #3
0. PREV
9. NEXT
