11
11 – 8
11
3) Log
SYNCHRO: 360X, 180X, 90X and 36X
PULSE: 800, 400, 200, 100
4) 2-axis log
NMEA0183 (VBW) (incompatible with electronic compass)
5) External event mark
Key input
6) Radar buoy
11.7 Outputable Signal
1) External alarm
2) Sub display unit signal (radar adaptor and operation analyzer)
3) Remote monitor (using vertical multi-scan monitor) (CFQ-8914 connector option)
11.8 Standard Equipment Configuration
Scanner unit: 1 unit
Display unit: 1 unit
Installation cable: Between display and scanner unit
Typ. 15m (scanner connector)
Performance monitor: 1 unit
Cable for Performance monitor: Typ. 15m
Installing tools: 1 set
Standard spare parts: 1 set
Hood: 1 unit
Installation manual: 1 (Japanese or English)
11.9 Installing Clearance between Equipment
Max. Typ.
Between scanner and display unit 30m 15m
Between performance monitor and display unit 30m 15m
11.10 Others (Optional)
ATA function (built-in): NCA-843
Plotter function (built-in): NDB-33
Cover made of duck: MTT305811
Installation cable (20m): CFQ-8681-20
Installation cable (30m): CFQ-8681-30
