5 – 2
5
This sub-section explains how to initialize ATA before operation.
5.1.1 Setting Collision Judgment Conditions : SAFE LIMIT
Values of collision judgment conditions should be properly set according to type of tracking ship,
particular waters, weather and sea conditions. (For relations between the judgment conditions and
alarms, see section “5.6 Alarm Display”.)
Before operation, be sure to set and check collision judgment conditions.
[I] Setting the CPA LIMIT (distance of safety limit) ／
TCPA LIMIT (time of safety limit)
Procedures
Procedures
1. Press the
SUB
MENU
key to open the SUB MENU.
2. Press the
5
key the ATA #1 menu.
3. Press the
5
key to select "LIMITS".
4. Press the
5
key.
5. Press the
0
to
9
keys to enter a numeric value.
6. Press the
ENT
key to fix the CPA LIMIT.
7. Press the
0
to
9
keys to enter a numeric value.
8. Press the
ENT
key to fix the TCPA LIMIT.
Exit
Exit
9. Press the
SUB
MENU
key.
ATA #1
1. ATA SYMBOL OFF ON
TAGET DATA OFF
ON
2. VECTOR TIME 5MIN (0-60MIN)
3. PAST POSITION OFF ON
4. PAST POSITION TIME 30 SEC
1 MIN 2 MIN 4 MIN
5. LIMITS CPA 5. 0NM (0.1-9.9NM)
TCPA 15MIN (1-99MIN)
5.1 Initialization
Attention
ATA #1 0. PREV
9. NEXT
