JRC JMA-7710-6 - Observation and Video Adjustment; Data Acquisition and Measurement; Ending Operation and Stopping the System

3
3 – 4
3.1
3.1.4 Observation and Video Adjustment
Procedures
Procedures
1. Press the
RANGE
key to select the range appropriate for observation.
2. Turn the
GAIN
and
BRILL
controls so that the target is displayed
most clearly.
3.1.5 Data Acquisition and Measurement
For details, see section “3.3 Basic Operation” and chapter “4 Measurement”.
3.1.6 Ending Operation and Stopping the System
To stop transmission
Procedures
Procedures
Press the
TX
STBY
switch.
This stops radar transmission and scanner unit rotation. "TX" on the upper left of the
screen changes to "STBY".
Keep the system in the standby mode if it is expected to be reset to the transmit mode
soon. This enables the user to select the transmit mode again simply by pressing the
TX
STBY
switch.
To turn off
Procedures
Procedures
Press the
PWR
switch to turn the system off.
This stops the power to be supplied to the system.
