8.1.2.3 Sensor Test
This test is used to check signals from the scanner unit.
Procedures
Procedures
1. Follow procedures 1 to 2 in subsection 8.1.2.1.
2. Press the
2
key to open the DIAGNOSTIC 1 menu.
3. Press the
1
key to open the SENSOR TEST menu.
"OK" is displayed when the bearing pulses (BP and BZ) are input in the display unit.
Exit
Exit
4. Press the
SUB
MENU
key.
Sensor Test
SAFETY KEY OK
BEARING PULSE (BP) OK
BEARING PULSE (BZ) OK
8.1.2.4 Line Test
This test is used to check the communication status with optional equipment.
Procedures
Procedures
1. Follow procedures 1 to 2 in subsection 8.1.2.3.
The DIAGNOSTIC 1 menu appears.
2. Press the
2
key to open the LINE TEST menu.
"ON" appears when communication or connection has been established.
Exit
Exit
3. Press the
SUB
MENU
key.
Line Test
NSK ON
UART1 ON
UART2 OFF
ATA ON
SENSOR
TEST
0. PREV
LINE TEST 0. PREV
