5 – 11
5.4.1 Vector Display
When a target and the own ship were veered or when a new target was acquired, the displayed vector
might reach the specified accuracy only when three minutes or more elapsed after acquired or veering.
The vector might contain errors according to the state of tracking even after three minutes or more
elapsed.
For the vector which indicates the forecast position of a target, there are two modes of true vector (TRUE)
and relative vector (RELATIVE), and each length can arbitrarily be changed from 0 to 60 minutes.
[I] Selecting the vector modes
Select the true vector display/relative vector display using the
MAIN
MENU
key.
Procedures
1. Press the
MAIN
MENU
key to open the MAIN MENU.
2. Press the
8
key to select "VECTOR".
3. Press the
8
key to select "TRUE" or "RELATIVE" and then the
ENT
key.
or
1. Press the
VECT
TRK
key.
Whenever it is pressed, TRUE/RELATIVE is changed.
The current vector mode is displayed at the lower right side of the screen. "T_VECT"
is displayed for the true vector display and "R_VECT" is displayed for the relative
vector display.
Main menu
1. RADAR/TRACK BRILL ● [DAY1]
2. RR/VRM/EBL BRILL ● [DAY1]
3. ATA BRILL ● [DAY1]
4. GRAPHIC DATA BRILL ● [DAY1]
5. PROCESS OFF PROC1 PROC2 PROC3
6. IR OFF
IR1 IR2 IR3
7. FLOATING EBL
OFF ON
8. VECTOR
TRUE RELATIVE
9. GRAPHIC DATA DISP OFF
5.4 Displaying the ATA Data
MAIN MANU
Attention
To Next Page
